Silent bearing kit HGV

The silent block tool kit for commercial vehicles enables quick and professional removal and insertion of slotted and closed silent blocks directly on the vehicle.

Features:

• Country of origin: Germany
• Customs tariff number: 82055980
• Contents (Qty of pieces): 12
• Total width: 442 mm
• Total height: 151 mm
• Total depth: 357 mm
• Net weight: 17,5 kg
• 1000 V insulated: No
• VDE certified: No
• Parts list (Text):

  1x KL-1010-1201 - Konische Hülse

  1x KL-1010-1205 - Druckstück, Ausbau Ø 60 mm

  1x KL-1010-1301 - Konische Hülse Ø 63 mm

  1x KL-1010-1305 - Druckstück, Ausbau Ø 63 mm

  1x KL-1010-1401 - Konische Hülse

  1x KL-1010-1402 A - Federndes Druckstück Ø 65 mm

  1x KL-1010-1406 - Druckstück, Ausbau Ø 65 mm

  1x KL-1010-2201 - Konische Hülse Ø 75 mm

  1x KL-1010-2202 - Federndes Druckstück Ø 75 mm

  1x KL-1010-2205 - Druckstück, Ausbau Ø 75 mm

  1x KL-1010-2401 - Konische Hülse Ø 51 mm

  1x KL-1010-2404 - Druckstück Ø 50 mm

  1x KL-1010-1090-1 - Schaumstoffeinlage

  1x KL-4600-1094 - Kunststoffkoffer

• Target groups: Construction and commercial vehicles Agriculture
• Suitable for: Universally compatible with slotted and closed silent blocks on commercial vehicles, with an outer diameter of (installed/uninstalled) 51/52, 60/62, 63/65, 65/70, 75/80 mm. Especially suitable for Mercedes Actros front leaf springs, Renault Midlum/D, Premium/T, Magnum/T, Kerax/C leaf springs or spring arms with silent block part numbers 7482054079, 5010557875, 7420839455, 7421622369, 7421646217, 7420929989; DAF 65 CF, 75 CF, 85 CF, LF55; Volvo FE, FM, FH, FMX leaf springs and bearing blocks; MAN TGA front spring bracket rear; Mercedes Actros front axle stabilizer bar; Mercedes Actros and Atego rear axle stabilizer bar; Volvo FM, FH and Renault, among others.
• Required accessories: Hydraulic drive (285 t): KL-1010-106 K - Drive kit 28 t for KL-1010 series KL-0215-35 M28 - Hydraulic pump
• Storage: L-BOXX
• Drive type: hydraulic
• Load (max.): 28 t
• For outer diameter, installed: 51 / 60 / 63 / 65 / 75 mm
