Reaction arm L-form straight for DVV13, 3/4"
Ready for shipment in 6 workdays
- Item number:
- WS03602653400
- Manufacturer number:
- RL-DVV13
- Weight:
- 0.762 kg
Reaction arm L-form straight for DVV13, 3/4"
Straight pattern, With adjustable reaction square, Made of light metal
Features:
- Country of origin: Germany
- Customs tariff number: 84679900
- Reach: compliant
- Contents (Qty of pieces): 1
- Net weight: 0,8 kg
- 1000 V insulated: No
- VDE certified: No
- Total length: 230 mm
- Material: Light metal
- Outside diameter: 75 mm
- Distance drive square - start reaction arm (min.): 60 mm
- Distance drive square - end reaction arm (max): 159 mm
- Version reaction arm: L-Form, straight
- Reaction arm mount: slipped over gear rim
- Height of flange ring: 20 mm
- Radius of flange ring: 35,5 mm
- Width reaction arm outer: 46,5 mm
- Height of locking handle: 30 mm
- Height square: 30,8 mm
